Ubiquiti UniFi Dream Machine Pro Max Gateway Router

An enterprise-grade all-in-one UniFi cloud gateway combining routing, security, switching, and NVR capabilities in a 1U rackmount device.

Specifications

• Brand/Model/Color: Ubiquiti UniFi Dream Machine Pro Max (UDM-Pro Max), Silver/Black
• Device type: Cloud gateway, router, security appliance, NVR
• Form factor: 1U rackmount
• Processor: 2 GHz ARM Cortex-A57 quad-core CPU
• Memory & storage: 8 GB DDR4 RAM, 32 GB eMMC, 128 GB SSD
• Performance: Up to 5 Gb/s IDS/IPS routing throughput
• Capacity: Supports 200+ UniFi devices, 2000+ clients
• Ports: 8 × RJ45 Gigabit LAN, 1 × 2.5G WAN, 1 × 10G SFP+ WAN, 1 × 10G SFP+ LAN
• Storage: 2 × 2.5"/3.5" HDD bays for UniFi Protect NVR recording
• Display: 1.3" touchscreen status display
• WAN features: Redundant WAN failover, load balancing, LTE backup support, internet quality monitoring, outage reporting
• Security features: Signature-based IPS/IDS, application-aware firewall, content/domain/country/ad filtering, full stateful firewall, VLAN/subnet traffic segmentation
• VPN & networking features: WireGuard/L2TP/OpenVPN server, OpenVPN client, IPsec site-to-site VPN, SD-WAN (license-free), policy-based routing for WAN/VPN, DHCP relay, customizable DHCP server, IGMP proxy, IPv6 ISP support, one-click Teleport and Identity VPN
• Integration: Full UniFi OS ecosystem (Network, Protect, Talk, Access)
• Use case: Enterprise networks, multi-site businesses, high-security environments, ISP deployments
• Feature highlights: 10G uplinks, multi-WAN failover, advanced VPN stack, IPS/IDS security engine, high client capacity
• Design: High-density enterprise gateway for large-scale UniFi infrastructure deployments
