• 11N speed allows for the best HD video streaming and internet calling experience*
• Dual external antennas deliver enhanced reception and transmission performance
• Easy one-touch wireless security encryption with the Quick Security Setup button
• 1.5 meter (4.9 feet)USB extension cable enables convenient, flexible deployment
• Supports Windows 10/8.1/8/7/XP, Mac OS, Linux

Technical Specifications

HARDWARE FEATURES

Interface: Mini USB 2.0

Button: WPS Push Button/Software

Dimensions ( W x D x H ): 3.5 x 2.7 x 0.7 in. (90 x 68 x 16.8mm)

Antenna Type: Dual Omni Directional

Antenna Gain: 3dBi

WIRELESS FEATURES

Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Frequency: 2.400-2.4835GHz

Signal Rate:

11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)

Reception Sensitivity:

270M: [email protected]% PER
130M: [email protected]% PER
108M: [email protected]% PER
54M: [email protected]% PER
11M: [email protected]% PER
6M: [email protected]% PER
1M: [email protected]% PER

Transmit Power: <20dBm(EIRP)

Wireless Modes: Ad-Hoc / Infrastructure mode

Wireless Security: Support 64/128 bit WEP, WPA-PSK/WPA2-PSK

Modulation Technology: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM

Advanced Functions: WMM

OTHERS

Certification: FCC, RoHS

System Requirements:

Windows 10/8.1/8/7/XP(32/64bit),
Mac OS X 10.9~10.13, Linux 2.6.24~4.9.60

Environment:

Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
