| Camera |
| Shutter Speed |
1/8000 to 64 Seconds
|
| Built-in ND Filter |
a 2 to 7 Stop Electronic ND Filter
|
| Minimum Illumination |
0.0013 Lux at f/1.9 Aperture
|
| White Balance |
ATW
Range: 2000 to 15,000K
|
| Zoom |
17x Optical
|
| Shutter |
Electronic Rolling Shutter
|
|
| Features & Benefits |
| Compatibility |
App Name: Monitor & Control
Yes: Android & iOS
|
| Shoe Mounting |
1x Cold Shoe
1x Hot Shoe
|
|
| Imaging/ Image Sensor |
| Image Sensor |
7.6 x 4 mm (1/2"-Type) 3-Chip CMOS
|
| Sensor Resolution |
Actual: 12.2 Megapixel
Effective: 8.29 Megapixel
|
| ISO Sensitivity |
Gain: -3 to 18 dB (-3 to 42 dB Extended)
|
| Image Stabilization |
Optical in Integrated Lens
|
|
| Lens |
| Focal Length |
5.6 to 95.2mm (35mm Equivalent: 30.3 to 515mm)
|
| Maximum Aperture |
f/1.9
|
| Minimum Aperture |
f/16
|
| Minimum Focus Distance |
From Front of Lens: 2" / 5 cm
|
|
| Focus & Optics |
| Focus Mode |
Manual Focus
Automatic (A)
|
|
| Viewfinder & Display |
| Viewfinder Type |
Support via Video Out Only
|
| Display Size (Diagonal) |
2.2″ (5.6 cm)
|
| Display Type |
Articulating Touchscreen LCD
|
| Display Resolution |
2,764,800 Dot
|
|
| Exposure Control |
| Interval Recording |
Time-Lapse Video
|
|
| Recording |
| Audio Recording |
MP4
MXF
XAVC: 4-Channel
|
| Media Card Slots |
Dual Slot: CFexpress Type A / SDXC
|
| Gamma Curve |
HDR-HLG
Rec2020
Rec709
S Cinetone
Sony S-Log 3
|
| Broadcasting Compatibility |
NTSC
PAL
|
|
| Audio |
| Built-In Microphone |
Stereo
|
|
| Connectivity |
| Wireless |
Wi-Fi 5 (802.11ac)
|
| GPS |
yes
|
|
| Performance |
| Tripod Mounting Thread |
1x 1/4"-20 Female
1x 3/8"-16 Female
|
|
| Interface |
| Video Output |
HDMI: 1920 x 1080i
HDMI: 1920 x 1080p
HDMI: 3840 x 2160
SDI/BNC: 1920 x 1080i
SDI/BNC: 1920 x 1080p
SDI/BNC: 3840 x 2160
|
| Video Connectors |
1x BNC (12G-SDI) Output
1x HDMI 2.0 Output
|
| Audio Connectors |
1x 1/8" / 3.5 mm TRS Stereo Headphone Output
2x XLR 3-Pin Microphone Input
|
| Other I/O |
1x 1/8" / 3.5 mm Control
1x 2.5 mm Sub-Mini (Remote)
1x BNC (Genlock, Reference)
1x BNC (Timecode) Input/Output
1x RJ45 (Gigabit Ethernet)
|
|
| Environmental |
| Operating Temperature |
32 to 104°F / 0 to 40°C
|
| Storage Temperature |
-4 to 140°F / -20 to 60°C
|
|
| General |
| Accessory Mounting Threads |
2x 1/4"-20
|
|
| Power |
| Power Consumption |
≥48 W
|
| Power Connectors |
1x USB-C (20VDC at 5 A) Input
|
| Battery Type |
1 x 1.5 V Button (Included)
Sony BP-U Series
|
|
| Physical |
| Dimensions (WxHxD) |
7.2 x 7.9 x 13.1" / 182.5 x 201.9 x 333.9 mm
|
| Weight |
5.7 lb / 2.6 kg (Body Only)
6.59 lb / 2.99 kg (With Battery)
|
|
