MikroTik SXTsq 5 High Power | 16dBi, 5GHz Integrated CPE/Backbone Antenna
![Buy MikroTik SXTsq 5 High Power | 16dBi, 5GHz Integrated CPE/Backbone Antenna in [storefront]](https://shopit.co.ke/images/thumbnails/40/40/detailed/62/1359_l.jpg.jpg "Buy MikroTik SXTsq 5 High Power | 16dBi, 5GHz Integrated CPE/Backbone Antenna in [storefront]"){kind=small}
![Buy MikroTik SXTsq 5 High Power | 16dBi, 5GHz Integrated CPE/Backbone Antenna in [storefront]](images/detailed/62/1359_l.jpg "Buy MikroTik SXTsq 5 High Power | 16dBi, 5GHz Integrated CPE/Backbone Antenna in [storefront]")
![Buy MikroTik SXTsq 5 High Power | 16dBi, 5GHz Integrated CPE/Backbone Antenna in [storefront]](images/detailed/62/1360_l.jpg "Buy MikroTik SXTsq 5 High Power | 16dBi, 5GHz Integrated CPE/Backbone Antenna in [storefront]")
![Buy MikroTik SXTsq 5 High Power | 16dBi, 5GHz Integrated CPE/Backbone Antenna in [storefront]](https://shopit.co.ke/images/thumbnails/50/50/detailed/62/1359_l.jpg.jpg "Buy MikroTik SXTsq 5 High Power | 16dBi, 5GHz Integrated CPE/Backbone Antenna in [storefront]")
![Buy MikroTik SXTsq 5 High Power | 16dBi, 5GHz Integrated CPE/Backbone Antenna in [storefront]](https://shopit.co.ke/images/thumbnails/50/50/detailed/62/1360_l.jpg.jpg "Buy MikroTik SXTsq 5 High Power | 16dBi, 5GHz Integrated CPE/Backbone Antenna in [storefront]")
RBSXTsq5HPnD
Please sign in so that we can notify you about a reply
The SXTsq 5 is a compact and lightweight outdoor wireless device with an integrated antenna, perfect for point-to-point links or as a CPE unit. It is compact, weatherproof and easy to mount. The SXTsq 5 retains a 16 dBi antenna like the SXT 5, our previous model, yet the antenna design has been improved and the physical size has been dramatically reduced - the SXTsq is two times thinner. Higher TX power allows to reach longer distances than SXTsq Lite 5.
Specifications
| Details | |
|---|---|
| Product code | RBSXTsq5HPnD |
| Architecture | MIPSBE |
| CPU | AR9344 |
| CPU core count | 1 |
| CPU nominal frequency | 600 MHz |
| Dimensions | 129 x 129 x 34 mm |
| License level | 4 |
| Operating System | RouterOS |
| Size of RAM | 64 MB |
| Storage size | 16 MB |
| Storage type | FLASH |
| Tested ambient temperature | -40°C to 70°C |
| Suggested price | $49.00 |
Powering
| Details | |
|---|---|
| PoE in | Passive PoE |
| PoE in input Voltage | 10-28 V |
| Number of DC inputs | 1 (PoE-IN) |
| Max power consumption | 7 W |
| FAN count | Passive |
Wireless specifications
| Details | |
|---|---|
| Wireless 5 GHz Max data rate | 300 Mbit/s |
| Wireless 5 GHz number of chains | 2 |
| Wireless 5 GHz standards | 802.11a/n |
| Antenna gain dBi for 5 GHz | 16 |
| Wireless 5 GHz chip model | AR9344 |
| Wireless 5 GHz generation | Wi-Fi 4 |
Ethernet
| Details | |
|---|---|
| 10/100 Ethernet ports | 1 |
Certification & Approvals
| Details | |
|---|---|
| Certification | CE, FCC, IC, EAC, ROHS |
Wireless specifications
| 5 GHz | Transmit (dBm) | Receive Sensitivity |
|---|---|---|
| 6MBit/s | 28 | -96 |
| 54MBit/s | 25 | -80 |
| MCS0 | 28 | -96 |
| MCS7 | 24 | -75 |
