Mecer BBONE-024S Lobo 2.4 KVA Solar Charger, Battery Bank and AVR

Cells Per Unit Voltage Per Unit Normal Operating Temperature Range Capacity Weight Max.
Discharge Current Internal Resistance Operating Temperature Range 6 12 o 100Ah @ 10hr-rate to 1.80V per cell @25 C Approx. 30.0 Kg (Tolerance±1.5%) 100(5 sec) Approx. 4 mΩ
 Discharge: -20C ~ 60C and Charge: 0 C~50 C
Float charging Voltage Recommended Maximum Charging Current Limit Equalization and Cycle Service Self Discharge Terminal Container Material Terminal F10 Dimensions o 13.6 to 13.8 VDC/unit Average at 25 C 60 A o 14.6 to 14.8 VDC/unit Average at 25 C Unit: mm RA12-200 (12V 100Ah)
  Constant Current Discharge Characteristics: A (25 C) o Constant Power Disch

Lobo 2.4 KVA with AVR with solar charger with battery bank and 12v100ah*2

Specifications and features
Product Code BBONE-024Sspacer
MODEL BBONE-024S
CAPACITY 2400VA/ 1440W
INPUT
Voltage 230 VAC
Acceptable Voltage Range 90-280 VAC
Frequency 50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode) ? 10%
Efficiency (Peak) 85%
Transfer Time 20 ms typical
Waveform (Batt. Mode) Simulated sine wave
BATTERY
Battery Type and Numbers 12 V 100Ah x 2
SOLAR CHARGER (Optional)
Note Solar Charge controller not included, will request to purchase separately
Maximum PV Array Open Circuit Voltage 60 VDC
Operating Voltage Range 30~32 VDC
Maxmum Solar Charge Current 50 A max
PROTECTION
Full Protection Overload, short circuit and polarity reserve protection
PHYSICAL
Dimension, D X W X H (mm) 345 x 400 x 450
Net Weight (kgs) 75.8
OPERATING ENVIRONMENT
Humidity 0 to 90% Relative Humidity(Non-condensing)
Operating Temperature 0 to 40
Storage Temperature -15 to 50
